TH650.1D Mono Block Thunder Amplifier
650W RMS Class D Amplifier
$449.95*
FREE!**
1 Year
New
Please wait...
|
|
|
The TH Series amplifiers are the lastest version of Thunder that are designed to exceed your expectation for how an amplifier should perform. Featuring anodized aluminum top covers and subtle MTX badging, these amplifiers incorporate high end materials with convection cooling functionality. Each TH Series amplifier is designed to perform to the highest standard and has undergone rigorous quality testing to ensure this standard is met. Three class D mono blocks and two class A/B multi channel amplifiers offer every car audio enthusiast a solution that fits their needs.
Features:
-
Anodized Aluminum Heat Sink
-
External Bass Control Included with Mono Blocks
-
"Clip" Light LED on Mono Blocks
Specifications:
|
Part Number:
|
TH650.1D
|
Patented Adaptive Class D Technology
(Patent No: US06753729):
|
x
|
|
Smart Engage:
|
x
|
|
Recommended StreetWires Amp Kit:
|
ZN5K-04 OR ZN3K-04
|
|
4Ω RMS Power Output:
|
250W x 1 Channel
|
|
Signal-to-noise Ratio (1 Watt):
|
75dB
|
|
2Ω RMS Power Output:
|
400W x 1 Channel
|
|
THD+N (Distortion) (1 Watt):
|
< 1%
|
|
1Ω RMS Power Output:
|
650W x 1 Channel
|
|
Topology:
|
Class D
|
|
Frequency Response (-3dB):
|
20Hz to 200Hz
|
|
Crossover:
|
Variable Low @40Hz to 200Hz, 24dB/Oct
|
|
Subsonic:
|
20Hz to 50Hz,12dB/Oct, Variable
|
|
Bass Boost:
|
+12dB @ 40Hz
|
|
Maximum Input Signal:
|
5V
|
|
Maximum Sensitivity:
|
250mV
|
|
Patented Adaptive Class D Technology (Patent No: US06753729):
|
x
|
|
Patented Power Supply: (US05598325):
|
x
|
|
Height:
|
7 1/16" (17.94 cm)
|
|
Width:
|
11 3/8" (28.89 cm)
|
|
Depth:
|
2 1/8" (5.4 cm)
|
Downloads:
Items Shipped:
|
1
|
TH650.1D 650W Thunder Amplifier
|
|
1
|
Owners Manual
|
|
4
|
Mounting Screws
|
|
1
|
Allen Wrench
|
|
1
|
External Bass Control
|
